7A | Duqueine-NA.com

1

Front Upright
2

FR Stub Axle
2

FL Stub Axle
3

Right Wheel Nut. Torque (Hot Wheel) 450 Nm Torque (Cold Wheel) 400 Nm
3

Left Wheel Nut
4

Stop Washer Upright Nut
5

Right Upright Nut. Torque 400 Nm
5

Left Upright Nut. Torque 400 Nm
6

Front Wheel Bearing Inside Spacer
7

Front Upright Steel Insert Replacement in factory only
8

Wheel Safety Pin Support
9

Speed Sensor Bracket
10

Speed Sensor Cap
11

Wheel Safety Pin Spring
12

Wheel Bearing
13

Wheel Safety Pin
14

Front Rim
15

Wheel Speed Sensor
16

Rim Valve
A

Torque 1 Nm
B

Torque 2.5 Nm
C

Torque 15 Nm
D

Torque 15 Nm
E

Torque 80 Nm
F

Torque 30 Nm
